application:low and medium pressure for use with mineral, vegetable, glycols, polyglycols, synthetic ester based oils, oils in water emulsion, water, diesel fuel.
construction
liner: smooth synthetic rubber resistant to oils and water
reinforcement:1high tensile steel braid
cover: synthetic rubber resistant to oils and ozone
Working temperature
-40℃ +100℃ (+120 ℃peak
| Inner | Braid | Outside | Working | Test | Burst | Bend | Weight | ||
| pressure | Radius | ||||||||
| Inches | mm | mm | mm | bar | psi | bar | bar | mm | Kg/m |
| 3/16 | 4.8 | 9.5 | 11.8 | 250 | 3570 | 600 | 1000 | 90 | 0.19 |
| 1/4 | 6.4 | 11.1 | 13.4 | 225 | 3210 | 540 | 900 | 100 | 0.22 |
| 5/16 | 7.9 | 12.7 | 15.0 | 215 | 3070 | 510 | 850 | 115 | 0.27 |
| 3/8 | 9.5 | 15.1 | 17.4 | 180 | 2570 | 435 | 720 | 130 | 0.36 |
| 1/2 | 12.7 | 18.3 | 20.6 | 160 | 2295 | 385 | 640 | 180 | 0.44 |
| 5/8 | 15.9 | 21.4 | 23.7 | 130 | 1855 | 315 | 520 | 200 | 0.51 |
| 3/4 | 19.0 | 25.4 | 27.7 | 105 | 1500 | 255 | 420 | 240 | 0.62 |
| 1" | 25.4 | 33.3 | 35.6 | 88 | 1255 | 210 | 350 | 300 | 0.98 |
| 1"1/4 | 31.8 | 40.5 | 43.5 | 63 | 900 | 150 | 250 | 420 | 1.22 |
| 1"1/2 | 38.1 | 46.8 | 50.6 | 50 | 715 | 120 | 200 | 500 | 1.49 |
| 2" | 50.8 | 60.2 | 64.0 | 40 | 570 | 96 | 160 | 630 | 2.32 |
